Size of surface x Height(mm)
Weight(kg)
2000 X 2000 X 250
2100
2000 X 3000 X 250
3500
3000 X 3000 X 250
4050
3000 X 4000 X 250
6800
3000 X 5000 X 250
7700
3000 X 6000 X 250
9200
Item
Size
Accuracy
Distance between grooves
250
±0.03
Width of groove
10
+0.007~+0.030
Depth of groove
8
±0.3
Straightness of groove
1000
Square of groove
±0.05
Parallel of groove
0.03
